Carlo Gavazzi SSR Solid State Relay 50A 600V
Astoria CMA 18460005, Wega WY18460005, San Marino
Used with the Astoria Plus4You and Wega Concept
The analog switching solid state relay from Carlo Gavazzi works in accordance with the phase angle control principle
Integral snubber network
Up to 600 AACrms operational voltage
Phase-angle control analog switching designed for use within resistive & slightly inductive loads
| Attribute | Value |
|---|---|
| Minimum Load Current | 250 mA |
| Maximum Load Current | 50 A |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 42 V ac |
| Maximum Load Voltage | 660 V ac |
| Minimum Control Voltage | 20 V ac, 22 V dc |
| Maximum Control Voltage | 48 V dc, 280 V ac |
| Switching Type | Zero Crossing |
| Terminal Type | Screw |
| Output Device | Varistor |
| Maximum Turn On Time | 1 s |
| Dimensions | 44.8 x 58.2 x 28.8mm |
| Operating Temperature Range | -20 → +70°C |
| Off State Leakage Current | <3 mA |
| Depth | 58.2mm |
| Height | 28.8mm |
| Length | 44.8mm |
| Control Voltage Range | 20 → 280 V ac, 22 → 48 V dc |
| Load Voltage Range | 42 → 660V ac |
